Huananzhi H61 M.2 Intel 2nd & 3rd Gen Motherboard with Pre-Installed Windows

Huananzhi H61 M.2 Intel 2nd & 3rd Gen Motherboard with Pre-Installed Windows

Supports Intel 2nd & 3rd Gen Processor

2x DDR3 1600/1333MHz, Maximum 16GB

1x M.2 2280 PCIEX4 2.0 20Gbps

100M Network Card

Pre-Installed Windows

Specification:

Brand: Huananzhi

Model: H61 M.2

CPU: Supports Intel 2nd & 3rd Gen Processor

Main Chipset: Intel H61

CPU Socket: Support Intel LGA1155

Memory Slot: 2 x DDR3 memory slot

Memory Standard: Support 2x DDR3 1600/1333MHz Memory，Max support 16GB

Storage Interface: 4 x SATA2.0 6Gbps

Expansion Slots: 1x PCI Express3.0x16，1x PCI Express2.0x1

Expansion Interface: 1x M.2 2280 PCIEX4 2.0 20Gbps

Soud Track: 5.1 sound card

Network Card: 100M network card

Power Interface: 24PIN+8PIN

FAN PIN: 1xCPU_FAN PIN，1xSYS_FAN PIN

Power Supply: 5-phase power supply

PCB Layers: 4-layer PCB

Rear Panel Interface: 1xPS/2 port，6xUSB2.0，1xRJ45 interface，1x3-hole audio interface，1x VGA，1x HDMI，1xDVI

Front Panel Interface: 1 x USB2.0 PIN，1 xFront audioPIN，1xCOM PIN

BIOS: AMI UEFI BIOS

Form Factor: mATX

Dimension: 215x168mm M-ATX

Warranty: 3 Years
