Cudy GS1016 16-Port Gigabit Ethernet Switch

Cudy GS1016 16-Port Gigabit Ethernet Switch

General

Description

Features and Specifications of Cudy GS1016 16-Port Gigabit Ethernet Switch

Key Features:

1. Store-and-forward switching method
2. Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3x and IEEE 802.3ab standards
3. 16x 10/100/1000Mbps Auto-Negotiation, Auto MDI/MDIX ports provide
4. Non-blocking switching architecture enables full wire-speed packet forwarding and filtering
5. Supports 8K MAC address auto-learning and auto-aging

Specifications:

1. Transmission Distance: 100Meter (328ft)
2. Ethernet Standard: IEEE 802.3/802.3u / 802.3ab
3. Switching capacity: 32G
4. MACAddress: 8K MAC address table
5. Transfer Rate: 14,880 pps for 10Mbps | 148,800 pps for 100Mbps | 148,8000 pps for 100Mbps
6. VLAN (1-14Ports): Port Isolation: Downlink designated ports are isolated from each other, and only transmit data with the uplink port.
7. Default: Standard Switch: All ports communicate freely
8. Extend (1-14Ports): Link Extension: The specified port speed drops to 10Mbps, max transmission distance is 250 meters.
9. LINK/ACT On: Green - The port is connecting
10. LINK/ACT Blinks: The port is receiving or transmitting data
11. LINK/ACT Off: The port is not linked successfully with the device
12. Power Supply: Built-in power supply
13. Voltage Range: Ac100~ 240V
14. Consumption: <15W
15. Operating Temperature: 0℃ ~ 40℃
16. Storage Temperature: -40℃ ~70℃
17. Operating Humidity: 10%~85% non-condensing
18. Storage humidity: 5%~85% non-condensing
19. Dimensions (L*W*H): 200 x 118 x 44mm
